WD블레이드-2D | |||||||
모델 | 크기 | 잎 | 나사 | wrench | |||
블레이드 직경 | 총 길이L | 유효 길이H | shank diameterd | ||||
WD13-2D-C20 | 13 | 88 | 29 | 20 | WDXT042004 | M1.6X4 | T6 |
WD13.5-2D-C20 | 13.5 | 89 | 30 | ||||
WD14-2D-C20 | 14 | 90 | 31 | ||||
WD14.5-2D-C20 | 14.5 | 91 | 32 | ||||
WD15-2D-C20 | 15 | 92 | 33 | ||||
WD15.5-2D-C20 | 15.5 | 3 | 34 | WDXT052504 | M2X4 | T6 | |
WD16-2D-C20 | 16 | 94 | 35 | ||||
WD16.5-2D-C20 | 16.5 | 95 | 36 | ||||
WC17-2D-C20 | 17 | 96 | 37 | ||||
WD17.5-2D-C25 | 17.5 | 109 | 38 | 25 | |||
WD18-2D-C25 | 18 | 110 | 39 | ||||
WD18.5-2D-C25 | 18.5 | 111 | 40 | WDXT063006 | M2.2X6 | T7 | |
WD19-2D-C25 | 19 | 112 | 41 | ||||
WD19.5-2D-C25 | 19.5 | 113 | 42 | ||||
WD20-2D-C25 | 20 | 114 | 43 | ||||
WD20.5-2D-C25 | 20.5 | 115 | 44 | ||||
WD21-2D-C25 | 21 | 116 | 45 | ||||
WD21.5-2D-C25 | 21.5 | 117 | 46 | ||||
WD22-2D-C25 | 22 | 118 | 47 | ||||
WD22.5-2D-C25 | 22.5 | 119 | 48 | ||||
WD23-2D-C25 | 23 | 123 | 49 | WDXT073506 | M2.5X6 | T8 | |
WD23.5-2D-C25 | 23.5 | 124 | 50 | ||||
WD24-2D-C25 | 24 | 125 | 51 | ||||
WD24.5-2D-C25 | 24.5 | 126 | 52 | ||||
WD25-2D-C25 | 25 | 127 | 53 | ||||
WD25.5-2D-C32 | 25.5 | 134 | 54 | 32 | |||
WD26-2D-C32 | 26 | 135 | 55 | ||||
WD26.5-2D-C32 | 26.5 | 136 | 56 | ||||
WD27-2D-C32 | 27 | 137 | 57 | ||||
WD27.5-2D-C32 | 27.5 | 138 | 58 | ||||
WD28-2D-C32 | 28 | 139 | 59 | ||||
WD28.5-2D-C32 | 28.5 | 14 | 60 | ||||
WD29-2D-C32 | 29 | 143 | 62 | WDXT094008 | M3.5X8 | T15 | |
WD29.5-2D-C32 | 29.5 | 144 | 63 | ||||
WD30-2D-C32 | 30 | 148 | 64 | ||||
WD30.5-2D-C32 | 30.5 | 149 | 65 | ||||
WD31-2D-C32 | 31 | 150 | 66 | ||||
WD31.5-2D-C32 | 31.5 | 151 | 67 | ||||
WD32-2D-C32 | 32 | 152 | 68 | ||||
WD32.5-2D-C32 | 32.5 | 153 | 69 | ||||
WD30-2D-C40 | 30 | 158 | 64 | 40 | |||
WD30.5-2D-C40 | 30.5 | 159 | 65 | ||||
WD31-2D-C40 | 31 | 160 | 66 | ||||
WD31.5-2D-C40 | 31.5 | 161 | 67 | ||||
WD32-2D-C40 | 32 | 162 | 68 | ||||
WD32.5-2D-C40 | 32.5 | 163 | 69 | ||||
WD33-2D-C40 | 33 | 164 | 70 | ||||
WD33.5-2D-C40 | 33.5 | 165 | 71 | ||||
WD34-2D-C40 | 34 | 166 | 72 | ||||
WD34.5-2D-C40 | 34.5 | 167 | 73 | ||||
WD35-2D-C40 | 35 | 168 | 74 | 40 | |||
WD35.5-2D-C40 | 35.5 | 169 | 75 | ||||
WD36-2D-C40 | 36 | 170 | 76 | ||||
WD36.5-2D-C40 | 36.5 | 171 | 77 | ||||
WD37-2D-C40 | 37 | 179 | 79 | WDXT125012 | M5X11 | T20 | |
WD37.5-2D-C40 | 37.5 | 180 | 80 | ||||
WD38-2D-C40 | 38 | 181 | 81 | ||||
WD38.5-2D-C40 | 38.5 | 182 | 82 | ||||
WD39-2D-C40 | 39 | 183 | 83 | ||||
WD39.5-2D-C40 | 39.5 | 184 | 84 | ||||
WD40-2D-C40 | 40 | 185 | 85 | ||||
WD41-2D-C40 | 41 | 187 | 87 | 40 | |||
WD42-2D-C40 | 42 | 189 | 89 | ||||
WD43-2D-C40 | 43 | 191 | 91 | ||||
WD44-2D-C40 | 44 | 193 | 93 | ||||
WD45-2D-C40 | 45 | 195 | 95 | ||||
WD46-2D-C40 | 46 | 197 | 97 | WDXT156012 | M6X15 | T25 | |
WD47-2D-C40 | 47 | 199 | 99 | ||||
WD48-2D-C40 | 48 | 201 | 101 | ||||
WD49-2D-C40 | 49 | 203 | 103 | ||||
WD50-2D-C40 | 50 | 205 | 105 | 40 | |||
WD51-2D-C40 | 51 | 207 | 107 | ||||
WD52-2D-C40 | 52 | 209 | 109 | ||||
WD53-2D-C40 | 53 | 211 | 111 | ||||
WD54-2D-C40 | 54 | 213 | 113 | ||||
WD55-2D-C40 | 55 | 215 | 115 | ||||
WD56-2D-C40 | 56 | 222 | 120 | WDXT186012 | |||
WD57-2D-C40 | 57 | 224 | 122 | ||||
WD58-2D-C40 | 58 | 226 | 124 | ||||
WD59-2D-C40 | 59 | 228 | 126 | 40 | |||
WD60-2D-C40 | 60 | 230 | 128 | ||||
WD61-2D-C40 | 61 | 232 | 130 | ||||
WD62-2D-C40 | 62 | 234 | 132 | ||||
WD63-2D-C40 | 63 | 236 | 134 | ||||
WD64-2D-C40 | 64 | 238 | 136 | ||||
WD65-2D-C40 | 65 | 240 | 138 | ||||
WD66-2D-C40 | 66 | 242 | 140 | ||||
WD67-2D-C40 | 67 | 244 | 142 | ||||
WD68-2D-C40 | 68 | 246 | 144 |
